Model | HRFS-0690 | HRFS-0560 | |||||
Dimensie | W (mm) | 690 ± 5 | 560 ± 5 | ||||
L (mm) | 1150 | 1150 | |||||
Enkele vork (mm) | 160 | ||||||
Heffen hoogtebereik | 85 mm-210 mm | ||||||
Bordmateriaal | Q235 koolstofstaal of roestvrij staal | ||||||
Dikte van plaat | 4 mm | 5 mm | 6 mm | 4 mm | 5 mm | 6 mm | |
Weegingscapaciteit | 2000 kg | 2500 kg | 3000 kg | 2000 kg | 2500 kg | 3000 kg | |
Divisiewaarde | 0,5 kg | ||||||
Indicator/display | A12E, A27, A23P Optioneel (Oiml & CE goedgekeurd) | ||||||
Laadcellen | 4 PCS Keli SQB, Zemie H8C Optioneel | ||||||
Display -aanwijzers | Aan/uit, nul, tare, kg/lb | ||||||
Transmissieafstand | RS232C ≤30m | ||||||
Stroomvoorziening | Oplaadbare batterij, AC 187 ~ 242V; 49 ~ 51Hz, DC 6V/4AH | ||||||
Junctiebox | 5 -gat 4 -draads plastic junction box, roestvrijstalen junction box is optioneel | ||||||
Signaalkabel | 40 cm enkele afgeschermde 4-core kabel | ||||||
Kleur | Standaard handgreep zwart en schaal body oranje, ≥20 stcs kunnen worden aangepast | ||||||
Verpakkingsmethode | 2 stks of 4 stcs of 6 stks in één houten geval |
